Moxa SFP-10GERLC-T

SFP+ module with 1 10GBase-ER port, LC connector for 40 km transmission, -40 to 85°C operating temperature

7.049,14 €

exkl. 19% USt. , (Standard)

Stk

SFP+ module with 1 10GBase-ER port, LC connector for 40 km transmission, -40 to 85°C operating temperature

		10G Ethernet SFP
		SFP-SR				SFP-LR	SFP-ER	SFP-ZR
Transceiver Type		Multi-Mode				Single-mode	Single-mode	Single-mode
Fiber Cable Type		OM1	OM2	OM3	OM4	G.652	G.652	G.652
Typical Distance		33 m	82 m	300 m	400 m	10 km	40 km	80 km
Wavelength	Typical (nm)	850				1310	1550	1550
	TX Range (nm)	840 to 860				1260 to 1355	1530 to 1565	1530 to 1565
	RX Range (nm)	840 to 860				1260 to 1355	1530 to 1565	1530 to 1565
Optical Power	TX Range (dBm)	-5 to -1				-8.2 to +0.5	-1 to +2	0 to +4
	RX Range (dBm)	-9.9 to +0.5				-14.4 to +0.5	-15.8 to -1	-23 to -7
	Link Budget (dB)	8.3				7.4	15	23
	Dispersion Penalty (dB)	3.9				3.2	3	3
Note: When connecting the SFP-ER or SFP-ZR, we recommend using an attenuator to prevent damage caused by excessive optical power.

Optical Fiber
- Typical Distance: To reach the typical distance of specified fiber transceiver, please refer to formula: Link budget(dB) > dispersion penalty(dB) + total link loss(dB)

Operating Temperature
- -40 to 85°C (-40 to 185°F)
  Note: When using the SFP-10GZRLC-T with the ICS-G7526A/G7528A/G7826A/G7828A and the MDS-G4000-4XGS/MDS-G4000-L3-4XGS Series, the maximum temperature is -10 to 60°C (14 to 140°F).
Storage Temperature (package included)
- -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity
- 5 to 95% (non-condensing)
